* 2 Color Pad Printing M/C : UPP-350H

TECHNICAL DESCRIPTION
• PRODUCTION CAPACITY : 40 pcs/ min
• AVAILABLE GOODS OUTDIA : 60~110
• AVAILABLE GOODS HEIGHT : 60~180mm
• AIR PRESSURE : 6~7 kgf/
• PRINTING COLOR : TWO COLOR
• CONVEYOR SPEED : 0~10m/ min
• PRINTING INK CONSUMPTION : 0.85g/ min
• MAIN POWER : NONE
• MAIN ELECTRIC POWER : 220/ 380V x 50/ 60 Hz x 2/3P
• AIR CONSUMPTION : 1.2/ min
• MACHINE SIZE : W1000 x L2400 x H1500
• MACHINE WEIGHT : 2,000 kg

APPLICATION
• THIS MACHINE IS SPECIALLY DESIGNED FOR PRINTING ON THE SURFACE OF AUTOMOTIVE OIL FILTER.
• ON THE CONCEPT OF AUTOMATIC LINE, THIS MACHINE WILL DO EXCELLENT AND UNIFORM IN QUALITY.




* UV or IR DRY OVEN : UUD-700

FEATURE
• CONVETOR BELT FEEDING & UV or IR DRY SYSTEM
• PRODUCT CAPACITY : 40~45 pcs/ min
• PRODUCT SIZE : 60~110

APPLICATION
• HOUSING PRINT INK DRY

OPTIONAL PART
• UV or IR DRY OVEN
• PRINTING PAD
• UV or IR INK & SQUEEZE
• UV LAMP or IR HEATER






* 2 COLOR PAD PRINTING AT THE FILTER HOUSING

FEATURET
• PRINTING IS VERY CLEAN AND PRECISE BY FEEDING ROLLER WITH SEVERAL ROLLER PAD
• IT IS ADEQUATE FOR MASS PRODUCTION BY CONVEYOR.
• PLC CONTROL SYSTEM INSTALLED
• CONVEYOR BELT FEEDING & TWELVE ROLLER(FOR TWO COLOR) SYSTEM
